$9,339.00
The Amflow PL electric mountain bike offers 850 watts of peak power in an ultra-light build weighing 19.2 kg. [1] With its unrivaled combination of power, range, weight, and intelligent features, this groundbreaking eMTB is built for the trailblazers.
Amflow PL’s ultra-light carbon fiber frame weighs just 2.27 kg, [2]for breathtaking speed and agility.
Powerful Drive, Smooth Assistance
Designed and manufactured by DJI, the Avinox Drive System is seamlessly integrated into Amflow PL, infusing the type of cutting-edge hardware and software that has made DJI an industry leader in drones and camera stabilization technology. The Avinox Drive Unit features a compound planetary gearset with an industry-leading power-to-size ratio.
The durable, high-strength polymer material inside the Drive Unit effectively suppresses noise during high-speed gearbox operation. With multiple precision sensors built-in, combined with advanced DJI algorithms, it provides a strong, smooth assistance for a wide range of scenarios and conditions.
Five Modes, Targeted Assistance
In addition to traditional assistance modes of Eco, Trail and Turbo, the DJI Avinox Drive System also features a specialized Auto mode, which adapts assistance in real-time based on road conditions and riding position. [3] Once enabled, Auto mode empowers users to tackle a wide variety of terrain types and gradients without having to switch modes.
For the most challenging trails or steep inclines, activate Boost mode to instantly get 120 N·m of torque and 1000W high-power assistance. [4]
Intelligent Walk Assist, Effortless Control
Additional information
Size | Size |
---|
Geometry
M | L | XL | XXL | ||
---|---|---|---|---|---|
A | Reach | 452mm | 475mm | 500mm | 525mm |
B | Stack Height | 618mm | 628mm | 641mm | 655mm |
C | Standover Height | 780mm | 785mm | 790mm | 795mm |
D | Front Center | 782mm | 810mm | 844mm | 873mm |
E | Fork Length | 570mm | 570mm | 570mm | 570mm |
F | Wheelbase | 1227mm | 1255mm | 1289mm | 1318mm |
G | Chainstay Length | 445mm | 445mm | 445mm | 445mm |
H | Bottom Bracket Drop | 29mm | 29mm | 29mm | 29mm |
I | Bottom Bracket Height | 345.5mm | 345.5mm | 345.5mm | 345.5mm |
J | Effective Top Tube Length | 595mm | 620mm | 648mm | 676mm |
K | Head Tube Angle | 64.5° | 64.5° | 64.5° | 64.5° |
L | Head Tube Length | 105mm | 115mm | 130mm | 145mm |
M | Actual Seat Tube Angle | 70° | 70° | 70° | 70° |
N | Effective Seat Tube Angle | 77° | 77° | 77° | 77° |
O | Seat Tube Height | 430mm | 450mm | 470mm | 500mm |
Parts Spec
Frame |
Amflow PL Carbon Frame |
Satin Silver |
150mm rear travel |
Compatible with 27.5″ and 29″ rear wheels |
E-Bike System |
Avinox M1 Drive Unit: 105 N·m |
Avinox Screen: 2-inch OLED Control Display |
Avinox Integrated Battery: 800Wh |
Avinox Wireless Controllers: Right and left sides |
Avinox Fast Charger: 12A/508W |
Rear shock |
FOX Float Performance |
Trunnion (185×55mm), custom tune, EVOL Air sleeve, 2-position lever |
Fork |
FOX 36 Performance |
160mm travel, GRIP Damper, 15×110mm, 44mm rake |
Transmission |
Rear Derailleur: SRAM GX Eagle 12-speed |
Chainring: SRAM Eagle Transmission E-MTB Chainring 104BCD 34T |
Shift Levers: SRAM GX Eagle Trigger Shifter|Single Click |
Cassette: SRAM PG-1230, 11-50T |
Chain: SRAM NX Eagle |
Crankset: DJI Avinox SL Crank (M/L: 155mm; XL/XXL: 160mm) |
Brakes |
Magura MT5 hydraulic disc brake, HC lever, 4-piston caliper w/ Shiftmix 3, 203mm MDR-C Rotor (front and rear) |
Wheels |
Amflow HMA-30 |
Rims: Alloy, 29”, 30mm internal width, 32H, tubeless ready |
Spokes: SAPIM E-Light J-bend |
Front Hub: Alloy, 2 sealed cartridge bearings, 15×110mm thru-axle, 32h, 6-bolt |
Rear Hub: Alloy, 4 sealed cartridge bearings, 148×12mm thru-axle, 32h, 6-bolt, 21T |
Tires |
Front: Maxxis Assegai MaxxTerra 29×2.5″ WT 3C EXO E-25 TLR |
Rear: Maxxis Dissector MaxxTerra 29×2.4″ WT 3C EXO+ E-25 TLR |
Handlebar |
Amflow Enduro Alloy Handlebar |
35mm rise, 800mm wide |
5-degree upsweep, 9-degree backsweep |
Grips |
Amflow Enduro Grips |
Stem |
Amflow Enduro Stem, One-piece CNC |
Length: 35mm |
Clamping diameter: 35mm |
Saddle |
Selle Royal SRX Plus |
Seatpost |
KS Rage-i |
M: 150mm |
L: 170mm |
XL/XXL: 190mm |
Accessories |
Quick Start Guide |
Torque Wrench (3~25 N·m, Hex 2/3/4/5/6mm, Torx® 25) |
Shock Pump |
Front and Rear Lights |
